316 Stainless Steel Sheet

Hot-rolled sheet 3 mm and over in thickness is commonly known as either “sheet” or “plate”. 1.4 This International Standard does not cover the following steel qualities: — steels intended for boilers or pressure vessels, or steels designated as commercial quality or drawing qualities (see ISO 3573)
Availability:
Quantity:
  • 316

After 304, this is the most common stainless steel on the market. Again it is an austenitic grade with the addition of 2–3% molybdenum which further improves corrosion resistance. It is often referred to as a marine grade stainless steel because of its effective resistance to chloride corrosion in comparison to other stainless steel grades.



The material has superior welding and forming qualities. Grade 316 will require post-weld annealing to promote maximum corrosion resistance, though this is not necessary if Type 316L is used.



316 & 316L steel plate and pipes have common properties and are often stocked with Dual Certification, where it is determined that both have properties and composition which comply with both steel types.


Surface Finished Of Stainless Steel

Surface    finish

Characteristics &   Application

NO 1

Hot-rolled surface,annealed and pickled,can be used as cold-rolling material,industial tanks   and chem i cal devices.

2D

Cold-rolled, an nealed and pick led with out skinpassing the dull prod ucts can be used   as auto mo bile parts, build ing materrials and pipings.

2B

The surface brightness and flatness of NO.2B is better than NO.2D. Then through a special         surfacetreament to improve its mechamical properties, N02B could nearly satisfy com pre hen

sive uses.

NO.3

Polished with abra sive belt of grit #100#120,have bet ter bright ness with dis con tin u ous coarse

stria, used as in ner and ex ter nal or na ments for building, elec tri cal ap pli anc es and kitchen

uten sils etc.

NO.4

Polished with abrasive belt of grit #150#180, have better brightness with discontinuous   coarse stria, but thinner than NO.3, are used as bathtud buildinginner and external   ornaments electrical appliances, kitchen utensils and food processing equipment etc.

#320

Polished with abrasive belt of grit #320, have better brightness with discontinuous coarse stria,

but thinner NO.3, are used as bathtub building   inner and external ornaments electrical

appliances kitchen utensils and food lprocessing equipment etc.

HL

Polished with abrasive belt of grit #150-320 on the No.4 finish and has continuous streaks,

mainly used as building   ornaments, elevators, door of building, frontal plate etc.

BA

Cold rolled, bright an nealed and skin-passed, the prod uct has ex cel lent bright ness and good re flex iv i ty like mirror,

used for lectrical appliances, mirror, kitch en apparatus, or na ment ma te ri als etc



We are ISO 9001:2008 certified company with more than 20 years steel experience & have exported to countries such as Argentina, Australia, Canada , Chile, Mexico , Colombia, Denark , Norway, Finland, Germany, UAE, France, Vietnam, Brazil, America, Hungary, Sri Lanka, Malaysia, Saudi Arabia, Thailand, Indonesia, India, Iraq, Kuwait , Isreal, Lebanon,Morocco, Iran, Taiwan, Singapore, Qatar, Japan, Spain, Italy, Peru, South Korea, Turkey,Russia ,Philippines, Rome, England etc.


If there is any questions , pls do not hesitate to contact us !

Mr.Jim

Mobile/Wechat  : +86 15902911689

Email : info@yklsteel.com


Chemical Composition

UNS No

Grade

C

Si

Mn

P

S

Cr

Mo

Ni

N

S31600

316

0.08

0.75

2.00

0.045

0.030

16.00/18.00

2.00/3.00

10.00/14.00

0.10

Mechanical Properties

UNS No

Grade

Proof Stress
  0.2% (MPa)

Tensile Strength
  (MPa)

Elongation
  A5(%)

Hardness Max

HB

HRB

S31600

316

205

515

40

217

95



316 Stainless Steel Sheet Application


It is been typically used for Off Shore Oil Drilling, Power generation, Petrochemical, Gas Processing, Pharmaceutical Equipment, Chemical Equipment, Heat Ex changers, Paper & Pulp Industry.
