17-4PH
17-4PH STAINLESS ROUND BAR
Provides an outstanding combination of high strength, good corrosion resistance, good mechanical properties at temperatures up to 600°F (316°C), and good toughness in both base metal and welds.
What We Can Offer ?
Stainless steel flat bar
Stainless steel round bar & Rod
Stainless steel square & rods
Stainless steel angle bar
Stainless steel hex bar
Stainless steel rectangle bar
Stainless steel channel
Stainless steel beam
Stainless steel hollow bar
Stainless steel bright bar
Stainless steel black bar
We are ISO 9001:2008 certified company with more than 20 years steel experience & have exported to countries such as Argentina, Australia, Canada , Chile, Mexico , Colombia, Denark , Norway, Finland, Germany, UAE, France, Vietnam, Brazil, America, Hungary, Sri Lanka, Malaysia, Saudi Arabia, Thailand, Indonesia, India, Iraq, Kuwait , Isreal, Lebanon,Morocco, Iran, Taiwan, Singapore, Qatar, Japan, Spain, Italy, Peru, South Korea, Turkey,Russia ,Philippines, Rome, England etc.
If there is any questions , pls do not hesitate to contact us !
Mr.Jim
Mobile/Wechat : +86 15902911689
Email : info@yklsteel.com
17-4PH STAINLESS ROUND BAR
Provides an outstanding combination of high strength, good corrosion resistance, good mechanical properties at temperatures up to 600°F (316°C), and good toughness in both base metal and welds.
What We Can Offer ?
Stainless steel flat bar
Stainless steel round bar & Rod
Stainless steel square & rods
Stainless steel angle bar
Stainless steel hex bar
Stainless steel rectangle bar
Stainless steel channel
Stainless steel beam
Stainless steel hollow bar
Stainless steel bright bar
Stainless steel black bar
We are ISO 9001:2008 certified company with more than 20 years steel experience & have exported to countries such as Argentina, Australia, Canada , Chile, Mexico , Colombia, Denark , Norway, Finland, Germany, UAE, France, Vietnam, Brazil, America, Hungary, Sri Lanka, Malaysia, Saudi Arabia, Thailand, Indonesia, India, Iraq, Kuwait , Isreal, Lebanon,Morocco, Iran, Taiwan, Singapore, Qatar, Japan, Spain, Italy, Peru, South Korea, Turkey,Russia ,Philippines, Rome, England etc.
If there is any questions , pls do not hesitate to contact us !
Mr.Jim
Mobile/Wechat : +86 15902911689
Email : info@yklsteel.com
Equivalent Grades for 17-4 PH Stainless Steel
17-4 PH UNS | 17-4 PH AMS | 17-4 PH Werkstoff | AISI/SAE | EN Designation |
UNS S17400 | AMS 5643 | 1.4548 | 630 | X5CrNiCuNb17-4-4 |
Chemical Composition
17-4PH Chemical Composition | ||
Element | Percent By Weight | |
C | Carbon | 0.07 maximum |
Mn | Manganese | 1.00 maximum |
P | Phosphorus | 0.04 maximum |
S | Sulfur | 0.03 maximum |
Si | Silicon | 1.00 maximum |
Cr | Chromium | 15.00 - 17.50 |
Ni | Nickel | 3.00 - 5.00 |
Cu | Copper | 3.00 - 5.00 |
Nb | Columbium | 0.15 - 0.45 |
17-4PH Physical Properties
· Melting Range: 2560-2625°F (1404-1440°C)
· Density: 0.2820 lb/in³
Mean Coefficient of Thermal Expansion (Annealed Condition) | |||
Temperature Range | Coefficients | ||
°C | °F | μm/m·°C | in/in/°F·106 |
21-93 | 70-200 | 10.8 | 6.0 |
21-204 | 70-400 | 10.8 | 6.0 |
21-316 | 70-600 | 11.2 | 6.2 |
21-427 | 70-800 | 11.2 | 6.3 |
17-4 PH Stainless Steel Properties
Condition | Ultimate Tensile | 0.2% Yield | Elongation | Reduction Of | Hardness | Hardness |
H900 | 190,000 | 170,000 | 10 | 40 | 388 | C40 |
H1025 | 155,000 | 145,000 | 12 | 45 | 331 | C35 |
H1075 | 145,000 | 125,000 | 13 | 45 | 311 | C32 |
H1150 | 135,000 | 105,000 | 16 | 50 | 277 | C28 |
H1150-M | 115,000 | 75,000 | 18 | 55 | 255 | C24 |
H1150-D | 125,000 | 105,000 | 16 | 50 | 255 min- | C24-33 |
Equivalent Grades for 17-4 PH Stainless Steel
17-4 PH UNS | 17-4 PH AMS | 17-4 PH Werkstoff | AISI/SAE | EN Designation |
UNS S17400 | AMS 5643 | 1.4548 | 630 | X5CrNiCuNb17-4-4 |
Chemical Composition
17-4PH Chemical Composition | ||
Element | Percent By Weight | |
C | Carbon | 0.07 maximum |
Mn | Manganese | 1.00 maximum |
P | Phosphorus | 0.04 maximum |
S | Sulfur | 0.03 maximum |
Si | Silicon | 1.00 maximum |
Cr | Chromium | 15.00 - 17.50 |
Ni | Nickel | 3.00 - 5.00 |
Cu | Copper | 3.00 - 5.00 |
Nb | Columbium | 0.15 - 0.45 |
17-4PH Physical Properties
· Melting Range: 2560-2625°F (1404-1440°C)
· Density: 0.2820 lb/in³
Mean Coefficient of Thermal Expansion (Annealed Condition) | |||
Temperature Range | Coefficients | ||
°C | °F | μm/m·°C | in/in/°F·106 |
21-93 | 70-200 | 10.8 | 6.0 |
21-204 | 70-400 | 10.8 | 6.0 |
21-316 | 70-600 | 11.2 | 6.2 |
21-427 | 70-800 | 11.2 | 6.3 |
17-4 PH Stainless Steel Properties
Condition | Ultimate Tensile | 0.2% Yield | Elongation | Reduction Of | Hardness | Hardness |
H900 | 190,000 | 170,000 | 10 | 40 | 388 | C40 |
H1025 | 155,000 | 145,000 | 12 | 45 | 331 | C35 |
H1075 | 145,000 | 125,000 | 13 | 45 | 311 | C32 |
H1150 | 135,000 | 105,000 | 16 | 50 | 277 | C28 |
H1150-M | 115,000 | 75,000 | 18 | 55 | 255 | C24 |
H1150-D | 125,000 | 105,000 | 16 | 50 | 255 min- | C24-33 |
Aerospace applications
Chemical and petrochemical applications
Pulp and paper
Food processing
Aerospace applications
Chemical and petrochemical applications
Pulp and paper
Food processing
